Positioning:
The optimal upright standing position has been fine tuned in the EasyStand evolv standing frame. By strategically positioning the axis points of the stander in line with the body’s natural axis points, options like the hip supports, lateral supports, and head support remain in place from the sitting position to the standing position, minimizing shear. When positioned correctly, the contoured seat enables a maximum over-center stretch for multiple body types. Evolv also accommodates for hip and knee contractures through strategic positioning of the footplates and optional independent knee pads.
Safety and convenience:
EasyStand evolv standing frame ensures a safe and functional transition to standing. It allows the user to elevate in three easy steps - adjust, transfer, and pump up. Both users and care providers are more at ease with the evolv because of the safe and simple lateral transfer with transitional support to standing.
Here at Mobility Equipment Recyclers, we pride ourselves in customer service, so reach out to us today! 401-294-4111
Product comes standard with
- Planar seat
- Transfer handles
- Black upholstery
- No-tray chest pad
- Two 5" front wheels
- Two 5" rear locking casters
- Height-only adjustable footplates
- Manual hydraulic actuator with handle
| Specifications | |
|---|---|
| Product Manufacturer | EasyStand |
| Product Model | Evolv Medium |
| SKU | EAS00002 |
| Product Weight | 147 LBS |
| Approximate Height Range | 4’0‐5’6 |
| Weight Limit | 200lbs |
| Seat Depth Range (from seat pivot) | 14" - 19" |
| Seat to Footplate Range (from seat pivot) | 11" - 18" |
| Knee Width (center to center) | 9" |
| Kneepad Depth Range (from seat pivot) | 3.5" - 5.75" |
| Seat Height | 21.5" |
| Seat Dimensions | 16"W x 17.5"L |
| Standard Tray Size | 21" x 24" |
| Tray/Chest Pad Depth Range (from seat pivot) | 0" - 10.5" |
| Standard Tray Height Range (from seat pivot) | 15.5" - 30.5" |
| Footprint (at widest points) | 26.5" x 33.5" |
| Weight of Basic Unit | 101lbs |
| Frame Color | Grey |
| Standard Upholstery Color | Black |
| Locking Caster Diameter | 5 |
| Footplates‐Plantar | 10 degrees in 3 increments |
| Footplates‐Dorsi | 10 in 3 increments |
| Footplates‐ Toe‐out | 15 degrees in 3 increments |
| Front Swivel Casters | Add 5 to Footprint |
| Adjustable/Removable Actuator Handle Range | +/- 15 Degrees from Neutral |
| Clear Angle Adjustable Tray (Angle range) | 0 - 35 Degrees |
| Large Contoured Adjustable Chest Pad (Approximate size) | 9.5" x 15" |
| Transfer Seat Dimensions | 20" W x 17.5" L |
| Independent Kneepad Roho Insert Size | 5" W x 7.5" L |
| X-Style Chest Vest | 11" L x 9.5" W |
| Velcro Positioning Belt | 26" - 55" |
| Condition | Used/Like New |
